? Flexible Gigabit access. With flexible 8/24/48 Gigabit interface access, NSW5130 Series is compatible with non-multiplexed SFP interfaces to enable high density Gigabit access and protect users’ investment. ? Multiple services. NSW5130 Series supports multicast protocols such as IGMP, IGMP Snooping , FRRP (fast ring network recovery) protocol and FLRP (fast link recovery protocol). ? Sound security control policy. NSW5130 Series provides multiple authentication modes based on MAC address, 802.1x, and Portal. It supports dynamic or static binding of user identity, such as user account, IP, MAC, VLAN, and interface. ? Rich QoS policy. NSW5130 Series supports traffic identification on interfaces. It provides multiple stream classifications based on source MAC address, destination MAC address, source IP address, destination IP address, TCP/UDP port number, protocol type, and VLAN. ? Outstanding management. Compatible with SNMPv1/v2/v3 standard network management protocol, NSW5130 Series provides CLI command lines and a Web management interface.
8*10/100/1000Mbps RJ45 PoE port, 2*1000Mbps SFP port
Switching capacity
20Gbps
Forwarding performance
14.88Mpps
Cooling Fans
1
Operating Temperature
0℃ to 45℃
Operating Humidity
5% to 95%, non-condensing
Indicator
PWR, RUN, LINK/ACT, POE
Max.PoE Power
125W
Power Supply
AC: 100 to 240V, 50/60Hz
Weight
1.8kg
Max.Power
8W (excluding POE)
Software Specification
MAC
Support static, dynamic, black hole MAC entries Support source MAC address filtering
Maintenance
Support real-time temperature detection and alarm Support SNMP, CLI, Web management, Support local and remote output of system logs, operation logs, debugging information
Security
Support authentication modes based on MAC, 802.1x, and Portal; support local and support local and centralized authentication Support dynamic ARP detection, one-click ARP binding, authorized ARP, ARP source suppression, ARP source address inspection Support port isolation, port security Support broadcast storm suppression Support SSH2.0
QoS
Support 8 priority queues per port Support traffic classification based on 802.1p/DSCP/TOS Support speed limit on ports and streams Support SP, WRR, SP + WRR queue scheduling
Ethernet
Support port aggregation, port mirroring, RSPAN, port isolation, port traffic identification
VLAN
Support 4K 802.1Q VLAN Support VLAN based on MAC/ IP subnet/authentication policy/interface VLAN Support GVRP Support QinQ
