? Supports unified configuration, management, and search on the software, convenient for rapid operation and maintenance of multiple devices; supports automatically discovering the connected video devices and generating a network topology on the software. ? Supports Web login, and device configuration and management on the Web interface ? Supports visiting the cloud by scanning the QR code. Allows to view the device status and network topology in real time on the app, and remotely restart the PoE power supply. ? Supports PoE power supply and allows to view the power; allows to enable or disable PoE power supply for the powered device; allows up to 250m power supply using a standard network cable. ? Supports the extend mode for up to 250m communication range and 10Mbps auto-negotiation rate. ? Allows to report port abnormal alarms to the software for realtime monitoring. ? Supports port priority. The packets received by the priority port will be forwarded first when the switch is fully loaded and the priority port will be powered first when the PoE power supply is full. ? All metal casing, secure and reliable.
Maximum total power: 250W Maximum PoE power for single port: 30W
PoE Mode
ModeA (1236), ModeB (4578)
Power Supply
AC: 100 to 240V, 50/60Hz
Max.Power
265W
Prior Ports
1 to 8
Cooling Fans
1
Operating Humidity
5% to 90% RH, noncondensing
Operating Temperature
0°C to 40°C (32°F to 104°F)
Indicator
Power: Steady on: Normal power input Off: Abnormal power input PoE: Off: The PoE port is not supplying power Steady on: The PoE port is supplying power normally Link/Act: Off: Disconnected to the port On: Connected to the port Blinking: Transmitting data MAX: Off: The total PoE power is less than 80% of the total power of the device Steady on: The total PoE power is higher than 85% of the total power of the device
Software Specification
Ethernet
Supports full duplex, half duplex, and auto-negotiation working modes. Supports port auto-negotiation rate. Supports port priority flow control. Supports a link aggregation group (consist of two uplink ports) Supports port flow statistics Supports enabling/disabling ports
VLAN
Supports both access and trunk modes; allows up to 32 VLANs with IDs from 1 to 4095
MAC
Support (up to 16K). Supports clearing the dynamic MAC address
POE
Allows to view PoE status and power. Allows to enable/disable PoE power supply.
Loop Detection
Loop Detection
QoS
Supports port rate limitation. Supports broadcast storm control.
Security
Supports port isolation (only for the downlink ports). Supports locking login IP address, up to 64 addresses can be locked
Maintenance
Supports N:1 port mirroring. Supports unified software configuration, management, and search. Supports discovering the connected video devices and generating a network topology on the software. Supports device upgrade, factory settings restoration, configuration import, configuration export, logs export, and device restart on the software.
System
Allows to view the device name, device model, serial number, current version, IP address, MAC address, DNS, operation time, etc. Allows to edit and manage the IP address and device name Supports single-user management, user authentication, and password modification Allows to view other switches information on the same network, up to 32 switches Allows to view the connected video devices information, up to 64 devices
